GCK、GCS、MNS low voltage withdrawable switchgear is designed according to the requirements of industry department, the majority of electricity users and design companies.

Feature

Designed According to The Requirements of Industry Department, The Majority of Electricity Users and Design Companies

High Technical Performance Indicators and It Can Adapt to The Development Needs of Electricity Market

Widely Used for Power Distribution Systems of Many Industries, Such As Power Plants, Petroleum, Chemical Engineering, Metallurgy, Textile and High-Rise Buildings

Used as Complete Low Voltage Power Distribution Device for Power Generation & Supplying Systems of Three-Phase, Ac, 50 Hz/60 Hz, 380 V/400 V/660 V Rated Voltage, 4000 A Rated Current

Used in The Places Where Automation is High and Connected with Computer Interface is Required, Such As Large Power Plants and Petrochemical Systems

Get Quote

Product Introduction

GCK、GCS、MNS low voltage withdrawable switchgear is designed according to the requirements of industry department, the majority of electricity users and design companies. It has high technical performance indicators and it can adapt to the development needs of electricity market. This kind of switchgear are widely used for power distribution systems of many industries, such as power plants, petroleum, chemical engineering, metallurgy, textile and high-rise buildings. It is used as complete low voltage power distribution device for power generation & supplying systems of three-phase, AC, 50 Hz/60 Hz, 380 V/400 V/660 V rated voltage, 4000 A rated current. It is also used in the places where automation is high and connected with computer interface is required, such as large power plants and petrochemical systems.







Working conditions



  • Temperature range: -5 °C to +40 °C, the average temperature within 24 hours should not exceed +35 °C.
  • Altitude: ≤ 2000 m, indoor application.
  • The relative humidity should not exceed 50% at the highest temperature +40 °C, and higher relative humidity is allowed at low temperature (90% at +20 °C). Condensation may appear because of temperature range, and this phenomenon should be considered.
  • Gradient: ≤ 5°, vertical installation.
  • Workplaces should be free of fire, explosion, severe vibration and chemical corrosion.





Basic technical parameters



Electric performance



Rated insulation voltage

690V(1000)V

Rated working voltage

380V、400V、690V

Maximum working current of main bus

6300A

Rated withstand current of main busbar

100kA/1s

Main busbar rated peak withstand current

220kA/0.1s

Maximum operating current of branch distribution bus (vertical bus)

2000A

Peak current of distribution bus (vertical busbar):



Standard type

105kA(Max)/0.1s

Reinforced type

176kA(Max)/0.1s

Protection level

IP41
