GTXGN AC Metal-enclosed Ring Switchgear
GTXGN AC Metal-enclosed Ring Switchgear

GTXGN AC Metal-enclosed Ring Switchgear

GTXGN-12 Solid-insulated Switchgear includes three cabinets of basic functional units: vacuum load switch cabinet, vacuum load switch & fuse cabinet combination, and vacuum circuit breaker cabinet, which applies to 10kV three phase AC 50Hz single bus bar system.

Feature

Applies to 10kv Three Phase Ac 50hz Single Bus Bar System

Provided with Line Control, Protection, Monitoring And Communication

Can be Used In Airport, Subway, Arge Building, Secondary Substation And Mining or Industrial Enterprises

Especially Suitable for Those Occasions with Narrow Place, Poor Environment, High Altitude and Maintenance Free Requirement

Get Quote

Product Introduction

SUMMARY



GTXGN-12 Solid-insulated Switchgear includes three cabinets of basic functional units: vacuum load switch cabinet, vacuum load switch & fuse cabinet combination, and vacuum circuit breaker cabinet, which applies to 10kV three phase AC 50Hz single bus bar system. As an equipment to receive and distribute electric energy, it is provided with line control, protection, monitoring and communication, and can be used in airport, subway, arge building, secondary substation and mining or industrial enterprises, especially suitable for those occasions with narrow place, poor environment, high altitude and maintenance free requirement.





OPERATING CONDITIONS



Altitude: not higher than 1000m;

Ambient temperature: upper limit +45℃ , lower limit -40℃ ;

Relative humidity: daily mean RH not more than 95%, monthly mean RH not more than 90%;

No obvious pollutions such as erosion or combustible gas;

No frequent violent vibrations, earthquake intensity not above 8-magnitude.

Note: the customers shall consult any deviations from normal service conditions with the manufacturer.





TECHNICAL SPECIFICATION



Model GTXGN-12
Rated Voltage 12KV
Frequency 50Hz
Rated Current 630A/1250A
Size 500mm*950mm*1650m
IP Grade IP4X
Accessories Specification
Maintenance Instruction Must be cleaned and put in a dry place





OUTLINE AND DIMENSION
