TDGC Series Single Phase AC Automatic Voltage Regulator

TDGC2 series voltage regulator is in the structure of adjustable self-coupling transformer. it winds coil on ring shaped core, the brush fits close to the polished surface of coil under the press effect of spring, rotating shaft drives the brush holder and make brush slide along with the coil surface.

Feature

Structure of Adjustable Self-coupling Transformer

Popular Application in Industries, Agriculture and Scientific Researches

Particularly Suited to Serve as Ancillary Facilities For Such Equipment as Various Machine Tools, Transistor Curve Tracers, Projecting TV Sets, and Analytical Instruments in Petroleum Industry, Etc.

Get Quote

Product Introduction

Overview



TDGC2 series voltage regulator is in the structure of adjustable self-coupling transformer. it winds coil on ring shaped core, the brush fits close to the polished surface of coil under the press effect of spring, rotating shaft drives the brush holder and make brush slide along with the coil surface. so that to change the contact position of brush, i.e.change the winding ratio of primary and secondary coils, this enables the output voltage to get smooth stepless control. All models find popular application in industries, agriculture and scientific researches, and are particularly suited to serve as ancillary facilities for such equipment as various machine tools, transistor curve tracers, projecting TV sets, and analytical instruments in petroleum industry, etc.



Product Technical Sheet of the TDGC2/TSGC2 voltage regulator

Input voltage

Single-phase: 220V±10%
Three-phase: line voltage 380V±10%

Output voltage

Single-phase: 0-250V±10%
Three-phase: line voltage 0-430V±10%

Efficiency

>95%

Waveform distortion

No additional waveform distortion

Temperature rise

<60℃

Dielectric strength

1500V/min

Insulation resistance

Single-phase >5MΩ Three-phase >2MΩ

Rated capacity(KVA)

5

Phase number

1

Frequency(Hz)

50

Input voltage(V)

220

Output voltage(V)

0~250

Output current(A)

20





Our factory



We are a professional manufacturer for produce of voltage stabilizer,power transformer and other middle voltage equipment. We have a factory in Wenzhou City,Zhejiang Province, China. And have branches all over the world, such as Tanzania, Uganda, Russia and so on.







Our workshop have a professional production and test equipment, which major in voltage stabilizer for more than 10 years. We always have the idea of voltage stabilizer quality control, technical method innovation,and customers feedback development.









Our Service



1.We can provide voltage stabilizer sample pieces.
2.We can make the special samples of voltage stabilizer as clients' requirement.
3.We can do everything before delivery. You only need to make the order of voltage stabilizer,then box designing,raw material preparing,product producing,delivery and documents preparing all can be done by ourselves.







Our Certificate



We has a lot of certificate of the voltage stabilizer quality report, test report,CE certificate, ISO certificate and so on. We can also do the specific certificate for client’s country. Such as CNCA,TUV etc.
