HLBWG Photovoltaic Grid-Connected Cabinet
HLBWG Photovoltaic Grid-Connected Cabinet

HLBWG Photovoltaic Grid-Connected Cabinet

lt can be used in solar photovoltaic power generation systems, and can also be used to convert, distribute and control electrical energy between photovoltaic inverters and transformers or loads.

Feature

Wide current coverage, up to 4000A, breaking capacity up to 80KA.

The cabinet body is fully assembled, easy to install and maintain.

Simple and easily operation, effectively reducing the mis- operation.

Fixed installation, large space, good heat dissipation.

Get Quote

Product Introduction

OVERVIEW



lt can be used in solar photovoltaic power generation systems, and can also be used to convert, distribute and control electrical energy between photovoltaic inverters and transformers or loads.



As for low-voltage grid-connected photovoltaic power stations, the distributed photovoltaic grid-connected cabinet can also be equipped with functions such as metering and protection. The cabinet body adopts C-type structure, which is stable and solid.



Photovoltaic grid-connected cabinet is a distribution equipment connecting photovoltaic power station and power grid, and is the total outgoing of photovoltaic power station in the photovoltaic power generation system, and its main role is to act as the dividing point between the photovoltaic power generation system and the power grid.





TECHNICAL PARAMETER



TYPE HLBWG
Max.input voltage 690VAC
Rate frequency 50Hz
Max.rated current 3150A
Measurement data Three-phase current, three-phase voltage, active power, apparent power,power factor, frequency, electricity
Communication method / protocol RS485 bus / standard MODBUS-RTU protocol
Temperature and humidity working temperature:-40-+85℃ humidity 95%, no condensation, no corrosive gas place
Altitude ≤4000m
Body material Hot-dip galvanized steel sheet/stainless steel/cold-rolled steel sheet
Protection level IP40
Dimension (W*D*H) 2260mm×800mm×600mm
lnstallation method Floor type
