HL Residential Hybrid Inverter
HL Residential Hybrid Inverter
HL Residential Hybrid Inverter

HL Residential Hybrid Inverter

Honle Group Co.,Ltd, a Chinese company based in Wenzhou Zhejiang, is creating the world's leading power electronics technology to design and manufacture energy storage, power quality products to effectively increase your efficiency, reduce your carbon footprint and save money in real-time.

Feature

Flexible
  Wide Input Voltage Range, Compatible with Lead-Acid or Lithium-Ion Batteries or Other Battery

Grace
  Fashion Appearance,Light Weight, Smart Operation, Natural Cooling, Low Noise ip65, Wall Mounted Design, Saving Space

Advanced
  Intelligent Energy Management System for Home, Power Dispatching and Demand Side Response Management. Power Quality Management and Compensation

Reliable
  Compatible Anti Counter Flow Function, Battery Reverse Connect Protection, Adapt to ThreE-phase Unbalanced Load

Get Quote

Product Introduction

OVERVIEW



Honle Group Co.,Ltd, a Chinese company based in Wenzhou Zhejiang, is creating the world's leading power electronics technology to design and manufacture energy storage, power quality products to effectively increase your efficiency, reduce your carbon footprint and save money in real-time.







FEATURES



• Flexible

Wide input voltage range, compatible with lead-acid or lithium-ion batteries or other battery



• Grace

Fashion appearance,light weight, smart operation, Natural cooling, low noise IP65, wall mounted design, saving space



• Advanced

Intelligent energy management system for home, Power dispatching and demand side response management. Power quality management and compensation



• Reliable

Compatible anti counter flow function, Battery reverse connect protection, Adapt to three-phase unbalanced load





TECHNICAL PARAMETER



  HL8RT HL10RT HL12RT HL15RT HL20RT
Efficiency
Max. efficiency 98.20%
European weighted efficiency 97.70%
lnput (PV)
Recommended max. Pv power 12,000wp 15,000wp 18,000wp 22,500wp 30,000wp
Max.input voltage 1000V
Operating voltage range 1000V
Start-up voltage 200V
Rated input voltage 600V
Max. input current per MPPT 25A
Max. short-circuit current 40A
Number of MPP trackers 2
Max.input number per MPP tracker 1/2
lnput (DC Battery)
Compatible Battery Lithium battery / Lead-acid
Operating voltage range 180V~800V
Max operating current 30A
Max charge Power 20,000W
Max discharge Power 8,800W 16,500W 13,200W 16,500W 22,000W
Number of battery branches 2
Output (On Grid)
Grid connection Three-phase
Rated output power 8,000W 10,000W 12,000W 15,000W 20,000W
Max.apparent power 8,800VA 11,000VA 13,200VA 16,500VA 22,000VA
Rated output voltage 220Vac / 380Vac, 230Vac / 400Vac, 3W/N+PE
Rated AC grid frequency 50Hz/60Hz
Max.output current 13.4 16.7 20.1 25.1 33.4
Adjustable power factor 1leading...1leading
Max.total harmonic distortion <3
Output (off Grid)
Rated output power 8,000W 10,000W 12,000W 15,000W 20,000W
Maximum apparent power 8,800VA 11,000VA 13,200VA 16,500VA 22,000VA
Rated output voltage 220V/230V
Rated power 50/60
Maximum output current 13.4 16.7 20.1 25.1 33.4
Power factor range 1leading...1leading
Features&Protections
Anti-lslanding protection Yes
DC reverse connection protection Yes
lnsulation monitoring Yes
DC surge protection Yes,compatible with TYPE ll protection class according to EN/IEC 61643-11
AC surge protection Yes,compatible with TYPE ll protection class according to EN/IEC 61643-11
Residual current monitoring Yes
AC overcurrent protection Yes
AC short-circuit protection Yes
AC overvoltage protection Yes
Electric energy management Yes
General Data
Operating temperature range -25~+60°C(-13℉~140℉)
Relative operating humidity 0%RH ~ 100%RH
Max.operating altitude 4000m (13,123ft.) (Derating above 2000m)
Cooling lntelligent air cooling
Display LED/APP
communication Bluetooth / RS485 / CAN / WIFI / LAN / GPRS / 4G (Optional)
weight (incl. mounting bracket) 50kg
Dimension (incl. mounting bracket) 604×539×314mm (23.8×21.2×12.4 inch)
Degree of protection IP65
Standard Compliance
Certificate EN/IEC 62109-1, EN/IEC 62109-2, IEC 62116
Grid connection standards VDE AR-N 4105 VDE V0124-100 EN50549-1
